2 - 10 Core RVVP Shielded Control Cable 0.2mm - 1.5mm 24 - 18 AWG Flexible

Name: 2 10 Core RVVP Shielded Control Cable 02mm 15mm 24 18 AWG Flexible
Brand: Minfeng
Price: 0.1 USD

Quality 2 - 10 Core RVVP Shielded Control Cable 0.2mm - 1.5mm 24 - 18 AWG Flexible for sale

Brand Name : Minfeng

Model Number : rvvp

Certification : ISO,CE,IEC,TUV,KEMA

Place of Origin : Hebei, China

MOQ : 100

Price : 0.1-5

Payment Terms : L/C,T/T

Supply Ability : 100KM/Week

Delivery Time : 10 Days

Corporation : Minfeng cable group

Cabletype : Control Cable

Sample : Available

Type : Low Voltage, KVV/KVVP/KVVR/KYJV

Conductor Shape : Round

Outerjacketmaterial : PVC / Polyethylene / Nylon

Application : Automotive, Marine, Industrial machinery

Material Shape : Round Wire

Contact Now

RVVP 2/3/4/5/6/7/8 Core Shielded Control Cable

Product Overview

High-quality RVVP shielded control cable available in multiple core configurations (2-8 cores) and cross-sectional areas ranging from 0.2mm to 6.0mm. This flexible cable is designed for industrial control applications requiring reliable signal transmission with electromagnetic interference protection.

Technical Specifications

Cross Sectional Area (mm²)	Cable Diameter (mm)	Insulation Thickness	Jacket Thickness	Max. Conductor Resistance (Ω/KM, 20°C)	Nominal Voltage (V)	100m/KG	Length per Roll
2*0.2	4.5±0.2	0.4	0.6	92.3	300/300	2.26	100m/roll 200m/roll
2X0.3	5.1±0.2	0.5	0.6	69.2	300/300	3.11	100m/roll 200m/roll
2X0.5	5.5±0.2	0.5	0.6	39	300/300	4.71	100m/roll 200m/roll
2X0.75	6.1±0.2	0.5	0.8	26	300/300	5.73	100m/roll 200m/roll
2X1.0	6.6±0.2	0.6	0.8	19.5	300/300	7.07	100m/roll 200m/roll
2X1.5	7.7±0.2	0.6	0.8	13.3	300/300	9.85	100m/roll 200m/roll
2X2.5	8.6±0.2	0.7	0.9	7.98	300/300	13.46	100m/roll 200m/roll
2X4.0	10.6±0.2	0.7	1.0	4.95	300/300	19.95	100m/roll 200m/roll
2X6.0	12.6±0.2	0.8	1.0	3.65	300/300	28.61	100m/roll 200m/roll
3x0.2	3.9±0.2	0.4	0.6	92.3	300/300	2.65	100m/roll 200m/roll
3X0.3	4.5±0.2	0.5	0.6	69.2	300/300	3.56	100m/roll 200m/roll
3X0.5	5.4±0.2	0.5	0.8	39	300/300	5.16	100m/roll 200m/roll
3X0.75	6.5±0.2	0.5	0.8	26	300/300	6.44	100m/roll 200m/roll
3X1.0	7.5±0.2	0.6	0.8	19.5	300/300	8.2	100m/roll 200m/roll
3X1.5	7.9±0.2	0.6	0.8	13.3	300/300	11.28	100m/roll 200m/roll
3X2.5	9.7±0.2	0.7	0.9	7.98	300/300	17.85	100m/roll 200m/roll
3X4.0	11.4±0.2	0.7	1.0	4.95	300/300	25	100m/roll 200m/roll
3X6.0	13.7±0.2	0.9	1.3	3.65	300/300	37	100m/roll 200m/roll
4x0.2	5.1±0.2	0.4	0.6	92.3	300/300	3.41	100m/roll 200m/roll
4X0.3	5.2±0.2	0.5	0.6	69.2	300/300	4.15	100m/roll 200m/roll
4X0.5	6.5±0.2	0.5	0.8	39	300/300	6.23	100m/roll 200m/roll
4X0.75	7.4±0.2	0.5	0.8	26	300/300	8.26	100m/roll 200m/roll
4X1.0	7.6±0.2	0.6	0.8	19.5	300/300	10.62	100m/roll 200m/roll
4X1.5	8.7±0.2	0.6	0.8	13.3	300/300	14.24	100m/roll 200m/roll
4X2.5	11.1±0.2	0.7	0.9	7.98	300/300	22.41	100m/roll 200m/roll
4X4.0	12.7±0.2	0.7	1.0	4.95	300/300	32.5	100m/roll 200m/roll
4X6.0	14.7±0.2	0.8	1.2	3.65	300/300	43.85	100m/roll 200m/roll
